Turnkey SMT Assembly

High-Density PCBA with Micron Accuracy

From 01005 component placement to multi-axis inspection, we deliver certified board assemblies engineered for high-reliability aerospace, medical, and robotics applications.

Technical Specifications

Engineered for Extreme Precision

Our automated SMT lines are calibrated for high-yield execution on complex, multi-layer assemblies, ensuring rapid prototyping and seamless transition to high-volume production.

01005 SMT Placement

Turnkey Sourcing

Billet-to-Box-Build

High-speed SMT lines placing microscopic 01005 components with repeatable precision.

Full component sourcing with real-time counterfeit detection, secure warehousing, and supply chain tracking.

Direct integration with our CNC machining division for seamless mechanical enclosure assembly.

Zero-Defect Protocol

Multi-Stage Verification

We eliminate assembly defects through a rigorous, closed-loop testing regimen. Every board undergoes automated optical inspection and 3D X-ray analysis to verify solder joint integrity beneath ball grid arrays.

100%

AOI & AXI Inspected

Functional testing protocols are executed to your exact specifications, ensuring first-article approval and flawless field performance in high-reliability environments.

We deliver comprehensive automated inspection reports and serialized test logs with every production run, providing full traceability for aerospace and medical compliance.

Request PCBA Quote

Ready to begin DFM review?

Upload your Gerber files and Bill of Materials. Our engineering team will deliver a comprehensive manufacturability review to optimize your production yield.
